    HJ-23000 Flexographic Offset Printing Machine Plate 2.38mm 1200mm 2 Colour

    Ask Lasest Price
    Brand Name : HJ
    Model Number : HJ-23000
    Certification : ce
    Price : 6000dollars
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1 tower /30days
    Delivery Time : four weeks
    • Product Details
    • Company Profile

    HJ-23000 Flexographic Offset Printing Machine Plate 2.38mm 1200mm 2 Colour

    HJ-23000 Flexographic Printing Machine

    HJ-23000 Flexographic Offset Printing Machine Plate 2.38mm 1200mm 2 ColourHJ-23000 Flexographic Offset Printing Machine Plate 2.38mm 1200mm 2 ColourHJ-23000 Flexographic Offset Printing Machine Plate 2.38mm 1200mm 2 ColourHJ-23000 Flexographic Offset Printing Machine Plate 2.38mm 1200mm 2 Colour

    Picture is just for your reference.

    1. Main Variables:

    A. Model: HJ-21300

    B. Material: Paper

    C. Max. Width of Printing: 1250mm

    D. Max. Length of Printing: 200-1200mm

    E. Max. Speed of Printing: 10-70m/min

    F. Thickness of Plate(including glue):2.38mm

    G.. Machine Dimension: 4200*2300*2300mm

    H. Machine Weight: 1600kg

    2. Unwind Unit:

    A. Max. Length of Roller: 1350mm

    B:Max. Length of Effective Roller: 1300 mm

    C:Dia. Of Roller: 76mm

    D:Max. Dia. Of Unwind: 1200mm

    E:Method of Unwind: EPC device, magnetic powder, automatic tension, air shaft

    F: Way of Laoding Paper Roll: Pneumatic type

    3. Traction Unit:

    A:Constitution of Traction: Rubber Roller and Chrome plated Roller

    B:Traction Zones: 2

    4:Printing Unit:

    A. Constitution of Printing: Chrome plated Roller, Rubber Roller, Anilox roller, Plate Cylinder, Doctor blade

    B:Girth of Plate Cylinder: 200-1200mm

    C:Material of Plate: Resin and Rubber

    D:Principle of Work: Helical Gears Drive

    E:Plated-glued roller adjusting: Pneumatic type

    F: Anilox roller: Ceramic Anilox roller: 1pc/per color

    5:Heating and Drying Unit:

    A. Type of Heating and drying : blowing first then heating

    B:Heating Zones : Heating Tubes 5Zones

    C:Power of Heating :7.5kw

    D:Assistance of Drying Length: 1m

    E:Small Fan:10pcs

    F:Power of Small Fan:35w/pc

    6:Electrical Parts:

    A.:Main motors: 2.2kw

    B:Ink-Transfer Motor:15w*2pcs

    C:An speed adjustable Inverter Equips With the Main Motor

    7:Rewind Unit:

    A:Max. Length of Roller: 1350mm

    B:Max. Length of Effective Roller: 1300mm

    C:Dia. of Roller: 76mm

    D:Max. Dia of Wind: 1200mm

    E:Way of Rewind: Surface Rolling, Air shaft, Pneumatic type

    8:Main Machine Specification List:

    A. Main Motor: 1 pc (Kangyuan, Ruian)

    B. Ink transfer motor: 1 pcs (Libang, China)

    C: Converter Motor 1 pc (Ruian)

    D: The inverter: 1pcs ( Kewo, Shenzhen)

    F: Small fan: 10pcs (Changcheng, Suzhou)

    G: Aluminum Rollers: (Ruian)

    H: Ceramic Anilox Roller: 1 pc/per color (Yuncheng)

    I:Rubber rollers: 1 pc/per color (own product)

    J:Low pressure Electrical parts :(Zhenju)

    K:Switches: (Schneider emluator)

    L:Electrical control Box: 1 set (own products)

    M:Main machine body: 1 set (own products)

    N:Main machine casting: 1set (Chuangxin Cast iron Co., Ltd, Henan)

    O:Pneumatic component: 1 set (Chuangfeng Qidong)

    9: Spare Parts For Free:

    Tool Box 1 set (1-10# screwdriver, oil gun, Inner Hexagon Spanner 1 set)

    Switches 2 pcs

    Contactor 2 pcs

    Heating tube 2 pcs

    Machine operation instruction 1 pc

    Inverter instruction 1 pc

    Printing cylinder 1set (Printing length 400mm)



    HJ-23000 Flexographic Offset Printing Machine Plate 2.38mm 1200mm 2 ColourHJ-23000 Flexographic Offset Printing Machine Plate 2.38mm 1200mm 2 ColourHJ-23000 Flexographic Offset Printing Machine Plate 2.38mm 1200mm 2 ColourHJ-23000 Flexographic Offset Printing Machine Plate 2.38mm 1200mm 2 Colour
