High Speed 8 Color Flexographic Printing Machine with ce Economic
Six Color Central Drum Flexo Printing Machine 6 Color
High Speed 8 Color Flexographic Printing Machine
Feature:
1.Take it easy, accurate color, long life.
2.Use motors, variable frequency speed control, saving electricity,
small running fluctuations.
3.Off printing roll auto stop the ink-running motor, and
up-printing roll automatic start running the ink.
4.Use special synchronous belt running, accurate printing size and
lower noise when working.
5.2sets heating devices, including central heating and constant
temperature control system for group control.
6.Low-roller special steel processing, and special process, and
plating thickness of 0.1mm protective layer of hard chromium.
7.Alloy roll with hard oxidation, treating by dynamic balance,
static balanced.
8.With cold wind bellows, and can effectively prevent produce with
ink adhesion after printing
9.Print produce are clear and good arrangement quality.
10.Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll
Main advantage:
- Adopts the synchronouls belt drive instead of Gear drive;
- Machine running more quite, higher printing precison, good quality;
- Machine more stability;
- High Mechanical speed: 130m/min ( without material, only machine running)
- High printing speed: 30-110m/min
- Single unwind & Single rewind
Main Technical Parameter
| Model | YT600 | YT-8800 | YT-81000 | YT-81200 | YT-81400 | YT-81600 |
| Max. Material width | 650mm | 850mm | 1050mm | 1250mm | 1450mm | 1650mm |
| Max. Printing width | 560mm | 760mm | 960mm | 1160mm | 1360mm | 1560mm |
| Printing Material | OPP:20~70μm,BOPP:18~60μm,PE:35~100μm,NY:20~50μm,
PET:12~60μm,CPP:20~60μm,paper: 20~100g/m2 |
| Printing color | PC:8+0;7+1;6+2;5+3;4+4 |
| Printing length | 7.5"-40"/7.5"-50" |
| Printing plate lifting system | Automatic Hydraulic press control |
| Mechanical speed | 110m/min |
| Printing speed | 10-90m/min |
| Anilox roller | Metal: 100-300LPI
Or
Ceramic anilx roller(200-1000LPI), single doctor blade |
| Register precision | Longitude:±0.20mm Transverse:±0.20mm |
| Rewinder/Unwinder DIA | ø 1000mm/ ø 1200mm |
| Electrical header | 24KW | 26KW | 28KW | 30KW | 32KW | 34KW |
| Master power | 32KW | 34KW | 36KW | 38KW | 40KW | 45KW |
| Dimension (L×W×H) | 5.0m
×
2.0m
×
3.8m | 5.0m
×
2.2m
×
3.8m | 5.0m
×
2.4m
×
3.8m | 5.0m
×
2.6m
×
3.8m | 5.0m
×
2.8m
×
3.8m | 5.0m
×
3.0m
×
3.8m |
| Bearing | Japan(NSK) |
| Unilateral bearing | ASNU (Germany) |
If you need other width Size or high speed machine, pls kindly
contact Ms RED Zhang directly:
0086-13819753629
If also other require of machine, can tell Ms RedZhang freely ! |
Sample:
1.Q:Are you machinery factory or trading company?
A:Yes,We are machinery factory,and we are professional manufacturer
for 25 years
and focus on bag making machine,printing machine,film blowing
machine,etc.
and we also have one trading company
2.Q:Where is your factory Located? How can we visit it?
A:Our factory is located in Ruian City,Zhejiang Province,China
From SHANGHAI City by flight is 40minutes,by train is 4hours.
From GUANGZHOU City by flight is 2hours.
3.Q:How many years guarantee?
A:In usually,we have given customer for one years guarantee.
4.Q:What is your delivery time?
A:About 30-40 days
5.Q:What`s the payment method?
A:We can accept T/T,L/C,Western Union,Moneygram, Etc.
6.What is your after-sale service ?
A:We will send our professional technician to install and test the
machine.
