Biodegradable PLA Pbat Polyethylene Polythene PE HDPE Plastic
Extruder Film Blowing Machine Price
Also can change screw by pe film blowing machine
lldpe film blowing machine
ldpe film blowing machine
hdpe film blowing machine
pe extruder
pe film making machine
pe extrusion machine
Machine Advantages
1, We use stronger steel plate for machine body, which make machine
more stable
2, Screw and barrel is nitrigened by 72 hours. 38 chromium
materials, it is very hard. Bimetal Materials Taiwan Quality
3, Hard
surface gearbox, the life can be more 10 years. GuoMao
Brand
4, Motor with
CE standard, more 10 years life, Siemens Brand.
5, Electric
parts is CHINT, best supplier in China.
6, Easy to operate and one worker can run 3 sets
7, Temperautre Controller: Omron Brand
8, Inverter: LG Brand
9, Ceramic Heater: Heating faster and Keep warm longer
Machine Parameters
| Model | SJ-50-600 | SJ-55-800 | SJ-60-1000 | SJ-65-1200 |
| Diameter of Screw | Φ50 | Φ55 | Φ60 | Φ65 |
| Max. Width of Folded Film(mm) | 200-600 | 300-800 | 400-1000 | 600-1200 |
| Single-face Thickness of Film(mm) | 0.006-0.10 | 0.006-0.10 | 0.006-0.10 | 0.006-0.10 |
| Max. Extrusion(kg/h) | 60kg/h | 70kg/h | 80kg/h | 90kg/h |
| L/D | 30:1 | 30:1 | 30:1 | 30:1 |
| Total Power (kw) | 28 | 36 | 40 | 50 |
| Driving Power(kw) | 15 | 18.5 | 22 | 30 |
| Cylinder cooling Power(kw) | 0.13*2 | 0.13*2 | 0.13*3 | 0.13*3 |
| Overall Dimensions(m) | 5.0×2.1×4.0 | 5.0×2.3×4.2 | 5.0×2.3×4.5 | 5.0*2.3*5 |
| Weight(kg) | 2500 | 2800 | 3000 | 3200 |
Machine Details
Name: Gearbox
1.Function:reduce the speed of transferring
2.Speed Rate:10:1
3.Gear:Hard surface
4.Gear:Hard surface type,high quality
5.Lubrication oil for transfering
6.Low noise and longer life
Main Motro:Siemens Brand
1.Running Speed:1400rpm
2.Motor Power:380V,3phase,Power can be changed
3.Motor Life:more 10years
Heater:Ceramic heater function
1.heating faster than stainless heater
2.life is longer to 5 years
3.keeping hot inside is longer than stainless save power
4.High quality ceramic and heating wire Inside.
Cover Stainless cover
1.Seperate stainless cover to control heater better and save the
power consuption
2.Separate blower on stainless cover
3.Nice outlook for stainless cover
4.High speed blower to cool barrel
Fast screen changer:
1.Save worker working time
2.Never leakage for material
3.Easily to change the fiter
Die head:Taiwan design high speed
1.#45 steel stronger
2.Surface treatment,which make film more transparent
3.Bigger size than normal,which improve the output of machines
Gusset copied from Taiwan
1.Gusset part is copy from Taiwan,easy to adjust
2.Wooden gusset part is make
Double vent air ring:
1.Two lip to cool the film,it is faster than one lip.So it can
improve the output of machine
2.It can do HDPE and LDPE film
