Product Description:
Super Speed Lamination Machine uses lamination grade LDPE, LLDPE,
PP, EVA, EAA as coating material, mainly designed for paper double
side coating. The actual production line speed reaches 260M/Min. In
addition, non-woven fabrics, woven bags and other products can also
be applied.
The whole machine is controlled by PLC, and the weight is more than
50 tons, to ensure that the stability of the equipment is still
maintained at a high speed of 260m/min.
Model | BT-BJLM1450/110X2 |
Screw diameter | φ110 mm |
Length diameter ratio of screw | 33:1 |
Width of finished product | 690-1350MM |
Film thickness | 0.01-0.10MM |
Mechanical design line speed | 275M/MIN |
Maximum extrusion capacity | 380KG/H |
Main motor power | 55KW |
Total power | 370KW |
Main unwinding diameter | ≤φ1300 MM |
Winding diameter | ≤φ1300 MM |
weight | 30T |
Dimensions | 23000*11000*3500MM |
Power source | 380V |
Machine Components:
1:Double Station Un-Winder
2:Auto-Splicer
3:Automatic-EPC
4:Traction
5:Corona Treater
(After treating can increase compounding ability)
6:Extruder
(With Static Mixer,T-Die Extrusion,ensure stable flow and extrusion
coating)
7:Three Roller Compounding
(Big Diameter Chill Roller, Double Jacket with Inner Spiral flow)
(Different Toughness standard of Silicon roller for different
usage)
8:Trimming Collection
9:Double Station Winder(Automatic Cutting and Changing)
